5 Saving your Visualizations

Saving graphics in R is, in theory, straightforward. We simply need to call a suitable device. There are a number of different plotting devices available. Here, we will introduce four examples: tiff(), png(), postscript(), and pdf(). The latter two should be used for vector graphics (e.g. line plots, point plots, polygon plots etc.), whereas tiff() and png() are preferable for raster graphics (e.g. photos, our density scatter plot in Figures 3.5 and 3.11, or anything pixel based).

All the graphics devices in R basically work the same way:

  1. Open the respective device (postscript, png, etc.),
  2. Plot (or in our case print()) the plot objects, and
  3. Close the device using dev.off() - otherwise the file will not be written to the hard drive.

In code, this is:

png("some_filename.png", width = 10, height = 10, units = "cm", res = 300)
## here goes your plotting routine, e.g.: xyplot(1:10 ~ 1:10)
dev.off()

Sounds rather easy, but as they say, the devil is in the details… Unfortunately, neither lattice nor ggplot2 graphics play very well with the respective graphics devices. Consider the following setting where we want to produce a .tiff output with a resolution of 300 dpi, a width of 17.35 cm, a height of 23.35 cm, the font family “ArialMT” and a point size of 18.

Instead of saving a graph, however, we only check whether the point size of 18 is passed correctly to the respective plotting environment (i.e. base graphics, lattice, and ggplot2).

tiff("test.tif", family = "ArialMT", units = "cm",
     width = 17.35, height = 23.35, pointsize = 18, res = 300)

# query base graphics graphical parameter text size (pointsize)
par()$ps
## [1] 18
# query lattice text size
trellis.par.get()$fontsize$text
## [1] 12
# query ggplot2 text size
theme_bw()$text$size
## [1] 11
# turn device off
invisible(dev.off())
## [1] TRUE

We see that neither lattice nor ggplot2 adhere to the specified point size, whereas base graphics do. Let’s try this for the other devices, too. First, png():

png("test.png", family = "ArialMT", units = "cm",
     width = 17.35, height = 23.35, pointsize = 18, res = 300)
# query base graphics graphical parameter text size (pointsize)
par()$ps
## [1] 18
# query lattice text size
trellis.par.get()$fontsize$text
## [1] 12
# query ggplot2 text size
theme_bw()$text$size
## [1] 11
# turn device off
invisible(dev.off())
## [1] TRUE

As you can see, png() behaves similar to tiff(). Now for eps():

postscript("test.eps", family = "ArialMT",
           width = 17.35 / 2.54, height = 23.35 / 2.54, pointsize = 18)
# query base graphics graphical parameter text size (pointsize)
par()$ps
## [1] 18
# query lattice text size
trellis.par.get()$fontsize$text
## [1] 12
# query ggplot2 text size
theme_bw()$text$size
## [1] 11
# turn device off
invisible(dev.off())
## [1] TRUE

Finally, for pdf():

pdf("test.pdf", family = "ArialMT",
    width = 17.35 / 2.54, height = 23.35 / 2.54, pointsize = 18)
# query base graphics graphical parameter text size (pointsize)
par()$ps
## [1] 18
# query lattice text size
trellis.par.get()$fontsize$text
## [1] 12
# query ggplot2 text size
theme_bw()$text$size
## [1] 11
# turn device off
invisible(dev.off()) # dev.off() is sufficient, invisible() suppresses text output
## [1] TRUE

… and we see that only base graphics really adhere to the supplied font size.

Alright, this was only a small exercise to highlight the fact that it is not straightforward to get that fine control over graphics output in R. But before we dive into this deeper, we will first need to know what it is that we want to achieve, meaning we need a precise definition of the guidelines our graphics output should adhere to. Generally, academic journals provide formatting guidelines for both figures and tables. These, however, differ from journal to journal so that it is impossible to come up with a one-fits-all solution here. Therefore, we will pick one of these guides to highlight the process of achieving the desired formatting which can then be adapted to any other formatting guide. Even though this is - in R terms - not directly related to exporting visualizations through different devices, these finer controls will be covered her. In the end, from an academic publishing point of view, this is exactly the point where we need to start thinking about these formatting issues.

Depending on the journal the formatting guidelines can be quite detailed, though some journals allow for more flexibility. Generally, there are a few parameters that the majority of journals define in their formatting guides. These include (but are surely not limited to):

  • file types
  • font size
  • font family (font type)
  • dimensions
  • resolution (in case of raster graphics)

In case of more rigid formatting guidelines, further rules may be imposed on:

  • color mode
  • background color
  • lines and strokes
  • file size
  • orientation

As an example, we will use the artwork guidelines from PLOS ONE, for which more details are listed here. For .tiff images, the requirements are as follows:

  • width: 8.30 cm (one-column images), 17.35 (two-column images)
  • maximum height: 23.35 cm (caption will not fit on the same page then)
  • minimum resolution: 300 ppi
  • compression: LZW
  • color mode: RGB (millions of colors), 8 bits per channel
  • background: white, not transparent
  • layers: a single layer called “Background”
  • font type, size: Arial, Times or Symbol, 6 to 12 pt
  • lines: line width between 0.5 to 1.5 pt
  • white space: a 2 pt white space around each figure is recommended
  • file size: 10 MB max

Additionally, some general remarks on software related issues can be found here, in which it reads:

Numerous programs can create figures but are not dedicated to working with graphics. These may be limited in their capability to create TIFFs or EPSs that comply with PLOS specifications. Such applications include ChemDraw, Haploview, PyMol, R, ImageMagick, Corel Draw, GeneSpring, Matlab, Origin, Prism, Sigmaplot, and Stata. To create a high-quality TIFF from images created in other applications, use the instructions below to convert to PDF and then to TIFF or EPS.

This basically means that we should not directly export our graphics from R to either .tiff or .eps (the only two file formats accepted by PLOS ONE), but rather save them as .pdf and then follow this guide on how to convert the .pdf to the accepted formats. Here, we will cover all of these, so whether you send an original R .tiff or convert it from the R .pdf is completely up to you.

Okay, so let’s start with the tiff() device…
